Tables
16.1 Instructions
Job planning
744 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
PO Polynomial coefficient for polynomial
interpolation
s
PGAsl
Polynomial interpolation (POLY, POLYPATH, PO, PL)
(Page 251)
POCKET3 Milling cycle, rectangular pocket (any
milling cutter)
BHDsl/BHFsl
POCKET4 Milling cycle, circular pocket
(any milling cutter)
BHDsl/BHFsl
POLF LIFTFAST retraction position m
PGsl/PGAsl
POLFA Start retraction position of single axes
with $AA_ESR_TRIGGER
m
PGsl
POLFMASK Enable axes for retraction without a
connection between the axes
m
PGsl
POLFMLIN Enable axes for retraction with a linear
connection between the axes
m
PGsl
POLY Polynomial interpolation m
PGAsl
Polynomial interpolation (POLY, POLYPATH, PO, PL)
(Page 251)
POLYPATH Polynomial interpolation can be
selected for the AXIS or VECT axis
groups
m
PGAsl
Polynomial interpolation (POLY, POLYPATH, PO, PL)
(Page 251)
PON Punching ON m
PGAsl
Punching and nibbling on or off (SPOF, SON, PON,
SONS, PONS, PDELAYON, PDELAYOF, PUNCHACC)
(Page 647)
PONS Punching ON in interpolation cycle m
PGAsl
Punching and nibbling on or off (SPOF, SON, PON,
SONS, PONS, PDELAYON, PDELAYOF, PUNCHACC)
(Page
647)
POS Position axis
PGsl
POSA Position axis across block boundary
PGsl
POSM Position magazine
FBW
POSP Positioning in sections (oscillating)
PGsl
POSRANGE Determine whether the currently
interpolated position setpoint of an axis
is located in a window at a predefined
reference position
PGAsl
Position in specified reference range (POSRANGE)
(Page 596)
POT Square
(arithmetic function)
PGAsl
Arithmetic functions (Page 63)
PR Per revolution
PGsl
