Tables
16.1 Instructions
Job planning
748 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
RTLIOF G0 without linear interpolation (single-
axis interpolation)
m
PGsl
RTLION G0 with linear interpolation m
PGsl
S Spindle speed
(with G4, G96/G961 different
significance)
m/s
PGsl
SAVE Attribute for saving information when
subprograms are called
PGAsl
Save modal G functions (SAVE) (Page 161)
SBLOF Suppress single block
PGAsl
Suppress single block execution (SBLOF, SBLON)
(Page 162)
SBLON Revoke suppression of single block
PGAsl
Suppress single block execution (SBLOF, SBLON)
(Page 162)
SC Parameter for access to frame data:
Scaling
PGAsl
Reading and changing frame components (TR, FI, RT,
SC, MI) (Page 290)
SCALE Programmable scaling s
PGsl
SCC Selective assignment of transverse axis
to G96/G961/G962. Axis identifiers may
take the form of geometry, channel or
machine axes
PGsl
SCPARA Program servo parameter set
PGAsl
Programmable servo parameter set (SCPARA)
(Page 278)
SD Spline degree s
PGAsl
Spline interpolation (ASPLINE, BSPLINE, CSPLINE,
BAUTO, BNAT, BTAN, EAUTO, ENAT, ETAN, PW, SD,
PL) (Page
234)
SEFORM Structuring operation in the Step editor
to generate the step view for HMI
Advanced
PGAsl
Structuring instruction in step editor (SEFORM)
(Page
215)
SET Keyword for initialization of all elements
of an array with listed values
PGAsl
Definition and initialization of array variables (DEF,
SET, REP) (Page 46)
SETAL Set alarm
PGAsl
Alarms (SETAL) (Page 688)
SETDNO Assign the D number of a cutting edge
(CE) of a tool (T)
PGAsl
Free assignment of D numbers: Rename D numbers
(GETDNO, SETDNO) (Page 431)
SETINT Define which interrupt routine is to be
activated when an NCK input is present
PGAsl
Assign and start interrupt routine (SETINT, PRIO,
BLSYNC) (Page 114)
