Syntax
WORKPIECE("<WP>", "<RefP>", "<ZeroOffset>", "<Type>", <Par5>,
<Par6>, ..., <Par12>)
Meaning
WORKPIECE(...): Predefined procedure for defining a blank
Preprocessing
stop:
Yes
Alone in the
block:
Yes
Parameters:
1 "<WP>": Name of the workpiece (optional)
Data type: STRING
A specification is only necessary if there can be several workpieces
in one channel. Without specifying, "WORKP<n>" is automatically
accepted, with <n> being the number of the declaring channel.
2 "<RefP>": Clamping (optional, only for milling machines)
Data type: STRING
Range of values: "Table" Clamping of the fixed table
"A" Clamping on rotary axis A
"B" Clamping on rotary axis B
"C" Clamping on rotary axis C
Precondition:
The table or the rotary axis must be enabled via the corresponding
machine data for the clamping of the blank (see SINUMERIK Oper‐
ate Commissioning Manual).
3 "<ZeroOffset>": Settable work offset for positioning the blank (not programmable)
The selection of a settable work offset for positioning the blank is only
offered for the blank entry via the user interface. For the direct defi‐
nition of the blank in the part program, the blank always relates to the
currently valid work offset.
4 "<Type>": Blank shape
Data type: STRING
Range of values: "CYLINDER": Cylinder
"PIPE": Pipe
"RECTANGLE": Centered cuboid
"BOX": Cuboid
"N_CORNER": Polygon with n edges
Work preparation
3.23 Additional functions
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1003
