No. Parameter
mask
Parameter
internal
Data type Meaning
16 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Representation of the beta value during
align tool
0 = Value
1 = Arrow
Note
If the following transfer parameters are programmed indirectly (as parameters), the screen
form is not reset: <_FR>, <_ST>, <_TC>, <_MODE>, <_DIR>
1)
Can be selected if the SWIVEL function is created in the commissioning
2)
Can be selected if direction reference to rotary axis 1 or 2 is set in IBN SWIVEL
If direction reference is "No" there is no selection field
3)
Swivel selection "No" can be grayed out SD 55221 Bit 0
Swivel "No", "Minus" direction corresponds to <_DIR> = 0 and _ST TEN THOUSANDS = 1
Swivel "No", "Plus" direction corresponds to <_DIR> = 0 and _ST TEN THOUSANDS = 2
4)
The direction selection for rotary axis 1 or 2 also occurs if the rotary axis with the direction
reference is in the pole position (position value equals zero).
5)
Coding example: Axis-by-axis rotation, rotary sequence ZYX
Binary: 00011011 Decimal: 27
The axis identifiers XYZ correspond to the geometry axes of the NC channel. Individual
rotations around the XYZ axes are permissible. For example, rotary sequence around ZXZ is
not permitted in one call of CYCLE800
3.25.1.35 CYCLE801 – grid or frame position pattern
Syntax
CYCLE801(<_SPCA>, <_SPCO>, <_STA>, <_DIS1>, <_DIS2>, <_NUM1>,
<_NUM2>, <_VARI>, <_UMODE>, <_ANG1>, <_ANG2>, <_HIDE>, <_NSP>,
<_DMODE>)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1097
