No. Parameter
mask
Parameter
internal
Data type Meaning
24 <_AMODE> INT Alternative mode
UNITS: Drilling depth = Final drilling depth Z1 (abs/inc)
0 = Compatibility, from programming <DP>/
<DPR>
1 = Incremental
2 = Absolute
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Thread direction of rotation right/left
0 = Compatibility, from PIT/MPTI sign
1 = Right
2 = Left
TEN THOUSANDS: Reserved
HUNDRED THOU‐
SANDS:
Reserved
ONE MILLION: Retraction distance after each machining step
V2 manual/automatic
0 = Compatibility, from <_VRT> program‐
ming (> 0 variable value or ≤ 0 standard
value 1 mm / 0.0394 inch)
1 = Automatic (standard value 1 mm / 0.0394
inch)
2 = Manual (programmed as under V2)
1)
Technology fields may be hidden, depending on the setting date SD52216 $MCS_FUNCTION_MASK_DRILL
2)
Parameters 19, 20 and 21 are only used for thread selection in the screen form thread tables. The thread tables cannot be
accessed via cycle definition in the cycle run time.
3.25.1.25 CYCLE85 - reaming
Syntax
CYCLE85(<RTP>, <RFP>, <SDIS>, <DP>, <DPR>, <DTB>, <FFR>, <RFF>,
<_GMODE>, <_DMODE>, <_AMODE>)
Parameter
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <RFP> REAL Reference point (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <DP> REAL Drilling depth (abs), see <_AMODE>
5 Z1 <DPR> REAL Drilling depth (inc), see <_AMODE>
6 DT <DTB> REAL Dwell time at final drilling depth, see <_AMODE>
Work preparation
3.25 Programming cycles externally
NC programming
1074 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
