5)
Measurement result display only for the calculated kinematics measuring version.
If the measurement result should also be displayed after the 1st to the 3rd measurement, then this is realized by setting the
channel-specific SD55613 $SCS_MEA_RESULT_DISPLAY.
6)
Rotary axis 2 only for kinematics with two rotary axes
7)
Limit value angular segment of the rotary axis. Value range of S_TNVL between 20 and 60 degrees. For values of S_TNVL
< 20 degrees, inaccuracies can be expected as a result of the measuring inaccuracies in the micrometer range of the probe.
If the limit value is violated, then error message 61430 is output – with a display of the minimum limit value.
8)
Spindle is tracked in the probe switching direction if SD54760 bit 17 = 1
3.25.3.13 CYCLE9960 measuring cycle parameters
PROC CYCLE9960(INT S_MVAR,STRING[40] S_TNAME,INT S_PRNUM,REAL S_SETV,REAL S_SETV1,REAL
S_START_RA1,REAL S_END_RA1,INT S_CMEA_RA1,REAL S_POS_RA2,REAL S_SETV2,REAL
S_START_RA2,REAL S_END_RA2,INT S_CMEA_RA2,REAL S_POS_RA1,REAL S_SETV4,REAL S_FA,REAL
S_TSA,INT S_NMSP,INT S_DMODE,INT S_AMODE,INT S_KNUM)
Table 3-20 CYCLE9960 call parameters
1)
No
.
Screen
form param‐
eters
Cycle pa‐
rameters
Meaning
1 Selection S_MVAR Measurement version (default=1)
Values: UNITS: Measuring variant
0 = measure and calculate kinematics (select with: Result display, protocol,
change of swivel data set (see thousands S_MVAR)
1 = measure reference head
2 = adapt head to reference head
3 = measure and calculate interpolation points (E996)
TENS: Reserved
HUNDREDS: Ball measuring variant
2 = measurement of the calibration ball and tracking of the spindle in the switch‐
ing direction of the probe
4 = paraxial measurement, with starting angle, tracking spindle in the switching
direction of the probe
2)
THOUSANDS: Calculate correction target for kinematics
3)
0 = measure and calculate. Data sets are calculated and remain unchanged
1 = calculated data sets may be changed after operator acknowledgment
2 = previously measured kinematics are calculated and, if applicable, changed
after operator acknowledgment
TENTHOUSANDS: Measuring axis (rotary axis 1 or 2)
1 = measure and calculate all existing rotary axes
4 = measure and calculate only rotary axis 1
5 = measure and calculate only rotary axis 2
2 S_TNAME Name of the transformation (swivel data set or transformation based on kinematic chains)
3 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
(default=1)
4 S_SETV Diameter of the calibration ball
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1187
