4.3.46 G group 46: Plane selection for fast retraction
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
LFTXT 1 The plane is determined from the path tangent and the
current tool orientation
+ m x
LFWP 2 The plane is determined by the current working plane
(G17/G18/G19)
+ m
LFPOS 3 Axial retraction to a position + m
4.3.47 G group 47: Mode switchover for external NC code
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G290 1 Activate SINUMERIK language mode + m x
G291 2 Activate ISO language mode + m
4.3.48 G group 48: Approach and retraction response with tool radius compensation
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G460 1 Collision detection for approach and retraction block
ON
+ m x
G461 2 Extend border block with arc if no intersection in TRC
block
+ m
G462 3 Extend border block with straight line if no intersection
in TRC block
+ m
4.3.49 G group 49: Point-to-point motion
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
CP 1 Path motion + m x
PTP 2 Point-to-point motion (synchronized axis motion) + m
PTPG0 3 Point-to-point motion only with G0, otherwise path mo‐
tion CP
+ m
PTPWOC 4 Point-to-point motion without compensationary motion,
which is caused by orientation changes
+ m
Tables
4.3 G commands
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1261
