Tool-specific parameters Meaning
$TC_TPG4 Minimum wheel width
$TC_TPG5 Actual wheel width
$TC_TPG6 Maximum speed
$TC_TPG7 Maximum circumferential velocity
$TC_TPG8 Angle of inclined wheel
$TC_TPG9 Parameter number for radius calculation
$TC_TPG_DRSPATH Directory path to the dressing program
$TC_TPG_DRSPROG Dressing program name
1)
The geometry length compensations, wear and base dimension can be chained for the left and right
tool nose radius compensation. This means that the length compensations for the left cutting edge are
changed so that the values are also automatically entered for the right cutting edge, and vice versa.
2.5.5.5 Turning tools
The following tool types are available in the "Turning tools" group:
500 Roughing tool
510 Finishing tool
520 Plunge cutter
530 Parting tool
540 Threading tool
550 Button tool / forming tool (TOOLMAN)
560 Rotary drill (ECOCUT)
580 Probe with cutting edge position parameters
Fundamentals
2.5 Tool offsets
NC programming
76 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
