No. Parameter
mask
Parameter
internal
Data type Meaning
8 DX <RPA> REAL Lift-off distance in X direction
9 DY <RPO> REAL Lift-off distance in the Y direction
10 DZ <RPAP> REAL Lift-off distance in the Z direction
11 SPOS <POSS> REAL Spindle position for lift-off (for oriented spindle stop, in degrees)
12 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Lift mode
0 = Lift off, compatibility
1 = Do not lift off contour
13 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
14 <_AMODE> INT
Alternative mode
UNITS: Drilling depth Z1 (abs/inc)
0 = Compatibility, from program‐
ming<DP>/<DPR>
1 = Incremental
2 = Absolute
TENS: Dwell time at final drilling depth DT in
seconds/revolutions
0 = Compatibility, from DT sign (> 0
seconds or < 0 revolutions)
1 = In seconds
2 = In revolutions
3.25.1.27 CYCLE92 - cut-off
Syntax
CYCLE92(<_SPD>, <_SPL>, <_DIAG1>, <_DIAG2>, <_RC>, <_SDIS>, <_SV1>,
<_SV2>, <_SDAC>, <_FF1>, <_FF2>, <_SS2>, <_DIAGM>, <_VARI>, <_DN>,
<_DMODE>, <_AMODE>)
Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 X0 <_SPD> REAL Reference point (abs, always diameter)
2 Y0 <_SPL> REAL Reference point (abs)
Work preparation
3.25 Programming cycles externally
NC programming
1076 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
