3.13 Tool offsets
3.13.1 Offset memory
Structure of the offset memory
Every data field can be called with a T and D number, and contains not only the geometric
specifications for the tool but also further entries, such as the tool type.
User cutting edge data
User cutting edge data can be configured via machine data. Please refer to the machine
manufacturer's instructions.
Tool parameters
Note
Individual values in the offset memory
The individual values of the offset memory P1 to P25 can be read and written by the program
via system variables. All other parameters are reserved.
The tool parameters $TC_DP6 to $TC_DP8, $TC_DP10 and $TC_DP11 as well as $TC_DP15
to $TC_DP17, $TC_DP19 and $TC_DP20 have another meaning depending on tool type.
Tool parameter number (DP) Meaning of system variables Remark
$TC_DP1 Tool type For overview see list
$TC_DP2 Cutting edge position Only for turning tools
Geometry Length compensation
$TC_DP3 Length 1 Allocation to
$TC_DP4 Length 2 Type and level
$TC_DP5 Length 3
Geometry Radius
$TC_DP6
1)
$TC_DP6
2)
Radius 1 / length 1
diameter d
Milling/turning/grinding tool
Slotting saw
$TC_DP7
1)
$TC_DP7
2)
Length 2 / corner radius, tapered milling tool
Slot width b corner radius
Milling tools
Slotting saw
$TC_DP8
1)
$TC_DP8
2)
Rounding radius 1 for milling tools
projecting length k
Milling tools
Slotting saw
$TC_DP9
1) 3)
Rounding radius 2 Reserved
$TC_DP10
1)
Angle 1 face end of tool Tapered milling tools
$TC_DP11
1)
Angle 2 tool longitudinal axis Tapered milling tools
Wear Length and radius compensation
$TC_DP12 Length 1
$TC_DP13 Length 2
Work preparation
3.13 Tool offsets
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 739
