Tool parameter number (DP) Meaning of system variables Remark
$TC_DP14 Length 3
$TC_DP15
1)
$TC_DP15
2)
Radius 1 / length 1
diameter d
Milling/turning/grinding tool
Slotting saw
$TC_DP16
1)
$TC_DP16
3)
Length 2 / corner radius, tapered milling tool, slot width
b corner radius
Milling tools
Slotting saw
$TC_DP17
1)
$TC_DP17
2)
Rounding radius 1 for milling tools
projecting length k
Milling / 3D face milling
Slotting saw
$TC_DP18
1) 3)
Rounding radius 2 Reserved
$TC_DP19
1)
Angle 1 face end of tool Tapered milling tools
$TC_DP20
1)
Angle 2 tool longitudinal axis Tapered milling tools
Tool base dimension/ adapt‐
er
Length offsets
$TC_DP21 Length 1
$TC_DP22 Length 2
$TC_DP23 Length 3
Technology
$TC_DP24 Clearance angle Only for turning tools
$TC_DP25 Reserved
1)
Also applies with milling tools for 3D face milling
2)
For slotting saw tool type
3)
reserved
Remarks
Several entry components are available for geometric variables (e.g. length 1 or radius). These
are added together to produce a value (e.g. total length 1, total radius), which is then used for
the calculations.
Offset values not required must be assigned the value zero.
Tool parameters $TC-DP1 to $TC-DP23 with contour tools
Note
The tool parameters not listed in the table, such as $TC_DP7, are not evaluated, i.e. their
content is meaningless.
Tool parameter number
(DP)
Meaning Cutting Dn Remark
$TC_DP1 Tool type 400 to 599
$TC_DP2 Cutting edge position
Geometry Length compensation
$TC_DP3 Length 1
$TC_DP4 Length 2
Work preparation
3.13 Tool offsets
NC programming
740 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
