Contour table KTAB:
After contour preparation is finished, the contour is available in both directions.
Index Column
Line (0) (1) (2) (3) (4) (5) (6) (7) (8) (9) (10)
0 6
1)
7
2)
11 100 100 20 20 0 45 0 0
1 0
3)
2 11 20 20 20 45 -3 90 0 0
2 1 3 11 20 45 0 45 0 0 0 0
3 2 4 12 0 45 -15 30 5 90 -15 45
4 3 5 11 -15 30 -30 30 0 0 0 0
5 4 7 11 -30 30 -30 45 -1111 90 0 0
6 7 0
4)
11 -30 80 -40 80 0 0 0 0
7 5 6 11 -30 45 -30 80 0 90 0 0
8 1
5)
2
6)
0 0 0 0 0 0 0 0 0
...
83 84 0
7)
11 20 45 20 80 0 90 0 0
84 90 83 11 20 20 20 45 -1111 90 0 0
85 0
8)
86 11 -40 80 -30 80 0 0 0 0
86 85 87 11 -30 80 -30 30 88 90 0 0
87 86 88 11 -30 30 -15 30 0 0 0 0
88 87 89 13 -15 30 0 45 -90 90 -15 45
89 88 90 11 0 45 20 45 0 0 0 0
90 89 84 11 20 45 20 20 84 90 0 0
91 83
9)
85
10)
11 20 20 100 100 0 45 0 0
Explanation of column contents and comments for lines 0, 1, 6, 8, 83, 85 and 91
The explanations of the column contents given in example 1 apply.
Always in table line 0:
1) Predecessor: Line n contains the contour end (forward)
2) Successor: Line n is the contour table end (forward)
Once each within the contour elements forward:
3) Predecessor: Contour start (forward)
4) Successor: Contour end (forward)
Always in line contour table end (forward) +1:
5) Predecessor: Number of relief cuts (forward)
6) Successor: Number of relief cuts (backward)
Once each within the contour elements backward:
7) Successor: Contour end (backward)
8) Predecessor: Contour start (backward)
Always in last line of table:
9) Predecessor: Line n is the contour table start (backward)
Work preparation
3.24 User stock removal programs
NC programming
1014 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
