Technology Technology cycle
Milling
● CYCLE61 - Face milling (Page 1044)
● POCKET3 – rectangular pocket (Page 1029)
● POCKET4 – circular pocket (Page 1032)
● CYCLE76 – rectangular spigot (Page 1055)
● CYCLE77 – circular spigot (Page 1058)
● CYCLE79 - multi-edge (Page 1062)
● SLOT1 - longitudinal slot (Page 1034)
● SLOT2 - circumferential slot (Page 1037)
● CYCLE899 – open slot (Page 1113)
● LONGHOLE - elongated hole (Page 1039)
● CYCLE70 - thread milling (Page 1051)
● CYCLE60 – engraving (Page 1041)
Contour milling
● CYCLE62 - contour call (Page 1046)
● CYCLE72 - Path milling (Page 1052)
● CYCLE63 – contour pocket milling / contour pocket residual ma‐
terial / contour spigot milling / contour spigot residual material
(Page 1046)
● CYCLE64 - Predrilling contour pocket (Page 1049)
Grinding
● CYCLE495 - form-truing (Page 1089)
● CYCLE435 - Set dresser coordinate system (Page 1089)
● CYCLE4071 - longitudinal grinding with infeed at the reversal
point (Page 1130)
● CYCLE4072 - longitudinal grinding with infeed at the reversal
point and cancel signal (Page 1132)
● CYCLE4073 - longitudinal grinding with continuous infeed
(Page 1136)
● CYCLE4074 - longitudinal grinding with continuous infeed and
cancel signal (Page 1137)
● CYCLE4075 - surface grinding with infeed at the reversal point
(Page 1140)
● CYCLE4077 - surface grinding with infeed at the reversal point
and cancel signal (Page 1143)
● CYCLE4078 - surface grinding with continuous infeed
(Page 1147)
● CYCLE4079 - surface grinding with intermittent infeed
(Page 1149)
Other
● CYCLE782 - adjust to load (Page 1091)
● CYCLE800 – swivel plane / swivel tool / align tool (Page 1094)
● CYCLE832 - High-Speed Settings (Page 1107)
All
● GROUP_BEGIN - beginning of program block (Page 1152)
● GROUP_END - end of program block (Page 1152)
● GROUP_ADDEND - End of trial cut addition (Page 1153)
Work preparation
3.25 Programming cycles externally
NC programming
1026 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
