Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <RFP> REAL Reference point of tool axis (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <_DP> REAL Slot depth (abs)
5 <_DPR> REAL Slot depth (inc) with respect to Z0 (enter without sign)
6 <NUM> INT Number of slots = 1
7 L <LENG> REAL Slot length
8 W <WID> REAL Slot width
9 X0 <_CPA> REAL Reference point in the 1st axis of the plane
10 Y0 <_CPO> REAL Reference point in the 2nd axis of the plane
11 <RAD> REAL Reserved
12 α <STA1> REAL Angle of rotation
13 <INDA> REAL Reserved
14 FZ <FFD> REAL Depth infeed rate
15 F <FFP1> REAL Feedrate
16 DZ <_MID> REAL Maximum depth infeed
17 <CDIR> INT Milling direction 0 = Down-cut
1 = Up-cut
18 UXY <_FAL> REAL Finishing allowance on plane or slot edge
19 <VARI> INT Machining type
UNITS:
0 = Reserved
1 = Roughing
2 = Finishing
4 = Edge finishing (only machine the
edge)
5 = Chamfering
TENS: Approach
0 = Predrilled, infeed with G0 (slot is
premachined)
1 = Vertically, infeed with G1
2 = Helical
3 = Oscillation
HUNDREDS: Reserved
20 DZF <_MIDF> REAL Reserved
21 FF <FFP2> REAL Reserved
22 SF <SSF> REAL Reserved
23 UZ <_FALD> REAL Finishing allowance, depth
24 ER <_STA2> REAL Radius of helical path on helical insertion
EW Maximum insertion angle for oscillation
25 EP <_DP1> REAL Insertion depth per rev for helix
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1035
