<_FFD>, <_CDIR>, <_VARI>, <_AP1>, <_AP2>, <_FS>, <_ZFS>, <_GMODE>,
<_DMODE>, <_AMODE>)
Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <_RTP> REAL Retraction plane (abs)
2 Z0 <_RFP> REAL Reference point of tool axis (abs)
3 SC <_SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <_DP> REAL Spigot depth (abs)
5 <_DPR> REAL Spigot depth (inc) with respect to Z0 (enter without sign)
6 L <_LENG> REAL Spigot length, see <_GMODE> (enter without sign)
7 W <_WID> REAL Spigot width, see <_GMODE> (enter without sign)
8 R <_CRAD> REAL Spigot corner radius (enter without sign)
9 X0 <_PA> REAL Reference point for spigot in 1st axis of plane (abs)
10 Y0 <_PO> REAL Reference point for spigot in 2nd axis of plane (abs)
11 α0 <_STA> REAL Angle of rotation, angle between longitudinal axis (L) and 1st axis of
plane
12 DZ <_MID> REAL Maximum depth infeed (inc; enter without sign)
13 UXY <_FAL> REAL Finishing allowance, plane (inc), allowance at edge contour
14 UZ <_FALD> REAL Finishing allowance depth (inc), allowance at base (enter without sign)
15 FX <_FFP1> REAL Feedrate on contour
16 FZ <_FFD> REAL Depth infeed rate
17 <_CDIR> INT Milling direction (enter without sign)
UNITS:
0 = Down-cut
1 = Up-cut
18 <_VARI> INT Machining
UNITS:
1 = Roughing
2 = Finishing
5 = Chamfering
19 L1 <_AP1> REAL Length of blank spigot
20 W1 <_AP2> REAL Width of blank spigot
21 FS <_FS> REAL Chamfer width (inc)
22 ZFS <_ZFS> REAL Insertion depth (tool tip) on chamfering (abs, inc), see <_AMODE>
Work preparation
3.25 Programming cycles externally
NC programming
1056 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
