No. Parameter
mask
Parameter
internal
Data type Meaning
9 <_AMODE> INT Alternative mode
UNITS: Drilling depth Z1 (abs/inc)
0 = Compatibility, from DP/DPR pro‐
gramming
1 = Incremental
2 = Absolute
TENS: Dwell time DT at final drilling depth in
seconds/revolutions
0 = Compatibility, from DT sign (> 0
seconds / < 0 revolutions)
1 = In seconds
2 = In revolutions
HUNDREDS: Drilling depth ZA abs/inc
0 = Incremental
1 = Absolute
THOUSANDS: Evaluation of predrilling feedrate
0 = As % of drilling feedrate
1 = F/min
2 = F/rev
TEN THOUSANDS: Remaining drilling depth ZD abs/inc
0 = Incremental
1 = Absolute
HUNDRED THOUSANDS: Evaluation of remaining drilling feedrate
0 = As % of drilling feedrate
1 = F/min
2 = F/rev
10 <_VARI> INT Predrilling/through-drilling machining type
UNITS: Reserved
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Through drilling
0 = Through drilling "No"
1 = Through drilling "Yes"
TEN THOUSANDS: Predrilling
0 = Predrilling "No"
1 = Predrilling "Yes"
11 ZA <S_ZA> REAL Incremental predrilling depth in relation to reference point or absolute
(see <_AMODE> HUNDREDS)
12 FA <S_FA> REAL Predrilling feedrate as value or in % (in conjunction with <_AMODE>
THOUSANDS)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1067
