No. Parameter
mask
Parameter
internal
Data type Meaning
24 <_PITA> INT Pitch unit (evaluation of PIT and/or MPIT)
0 = Pitch in mm - MPIT/PIT evalua‐
tion
1 = Pitch in mm - PIT evaluation
2 = Pitch in TPI - PIT evaluation
(threads per inch)
3 = Pitch in inches - PIT evaluation
4 = MODULE - PIT evaluation
25 <_PITM> STRING[15] String as marker for pitch input (for the interface only)
1)
26 <_PTAB> STRING[20] String for thread table (for the interface only)
1)
27 <_PTABA> STRING[20] String for selection in the thread table (for the interface only)
1)
28 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Type of thread
0 = Longitudinal thread
1 = Face thread
2 = Tapered thread
HUNDREDS: --- Reserved
THOUSANDS: --- Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Basic
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1087
