Table 3-11 CYCLE976 call parameters
1)
No
.
Screen
form param‐
eter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measuring version (default=1000)
Val‐
ues:
UNITS: Calibration on surface, calibration ball or in calibration ring
2)
0 = Length on surface with known setpoint
1 = Radius in calibration ring with known diameter (setpoint) and known center point.
2 = Radius in calibration ring with known diameter (setpoint) and an unknown center
point
3 = Radius and length at the calibration ball
4 = Radius at the edge with known setpoint. Note selection of measuring axis and
measuring direction.
3)
5 = Radius between two edges with known setpoint and edge clearance. Measuring
axis should be selected.
TENS: Reserved
0 = 0
HUNDREDS: Reserved
0 = 0
THOUSANDS: Selection of measuring axis and measuring direction during calibra‐
tion
0 = No specification (no selection of the measuring axis and measuring direction
required)
8)
1 = Specify selection of measuring axis and measuring direction, see S_MA, S_MD
(one measuring direction in a measuring axis)
2 = Specify selection of measuring axis, see S_MA (two measuring directions in a
measuring axis)
TEN THOUSANDS: Determination of the positional deviation (probe skew)
2)
0 = Determine positional deviation of the probe
6)
1 = Do not determine positional deviation
HUNDRED THOUSANDS: Paraxial calibration or at an angle
0 = Paraxial calibration in the active WCS
1 = Calibration at an angle
7)
ONE MILLION: Determination of tool length during calibration on surface or on ball
0 = Tool length is not determined
1 = Tool length is determined
4)
2 = Infeed axis is calibrated at the ball, the tool length is determined, the tool length
measured difference is entered in the calibration data
2 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
(default=1)
3 S_SETV Setpoint
4 Z0 S_SETV0 Setpoint of the longitudinal reference for ball calibration
5 X / Y / Z S_MA Measuring axis (number of the axis)
2), 6)
(default=1)
Val‐
ues:
1 = 1st axis of the plane (for G17 X)
2 = 2nd axis of the plane (for G17 Y)
3 = 3rd axis of the plane (for G17 Z)
