Data area G70 / G71 G700 / G710
Read Write Read Write
Interpolation parameters I, J, K P P P P
Circle radius (CR) P P P P
Polar radius (RP) P P P P
Thread pitch P P P P
Programmable FRAME P P P P
Settable FRAMES G G P P
Basic frames G G P P
External work offsets G G P P
Axial preset offset G G P P
Working area limits (G25/G26) G G P P
Protection areas P P P P
Tool offsets G G P P
Length-related machine data G G P P
Length-related setting data G G P P
Length-related system variables G G P P
GUDs G G G G
LUDs G G G G
PUDs G G G G
R parameters G G G G
Siemens cycles P P P P
Jog/handwheel increment factor G G G G
P: Writing/reading is performed in the programmed system of units.
G: Writing/reading is performed in the configured basic system
Synchronized actions
Note
Reading position data in synchronized actions
If a system of units has not been explicitly programmed in the synchronized action (condition
component and/or action component) length-related position data in the synchronized action
will always be read in the parameterized basic system.
Further information: Function Manual, Synchronized Actions
Fundamentals
2.8 Geometry settings
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 161
