User variables must be defined before they can be used (read/write). The following rules must
be observed in this context:
GUDs must be defined in a definition file, e.g. _N_DEF_DIR/_N_UGUD_DEF.
PUDs and LUDs must be defined in the definition section of the NC program.
The data must be defined in a dedicated block.
Only one data type may be used for each data definition.
Several variables of the same data type can be defined for each data definition.
Syntax
LUD and PUD
DEF <type> <phys_unit> <limit values> <name>[<value_1>, <value_2>,
<value_3>]=<init_value>
GUD
DEF <range> <pp_stop> <access_rights> <data class> <type>
<phys_unit> <limit values> <name>[<value_1>, <value_2>,
<value_3>]=<init_value>
Meaning
DEF: Command for defining GUD, PUD, LUD user variables
<range>: Range of validity, only relevant for GUD:
NC: NC-global user variable
CHAN: Channel-global user variable
<PP_stop>: Preprocessing stop, only relevant for GUD (optional)
SYNR: Preprocessing stop when reading
SYNW: Preprocessing stop when writing
SYNRW: Preprocessing stop when reading/writing
<access rights>: Protection level for reading/writing GUD via NC program or OPI (optional)
APRP <protection level>: Read: NC program
APWP <protection level>: Write: NC program
APRB <protection level>: Read: OPI
APWB <protection level>: Write: OPI
<protection level>: Range of values: 0 ... 7
See "Attribute: Access rights (APR, APW, APRP, APWP, APRB, APWB)
(Page 412)"
<data class>: Data class assignment (only SINUMERIK 828D)
DCM: Data class M (= Manufacturer)
DCI: Data class I (= Individual)
DCU: Data class U (= User)
Work preparation
3.1 Flexible NC programming
NC programming
398 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
