Examples
Example 1: Resuming in the main program after ASUB execution
Programming Comment
N10010 CALL "UP1" ; Program level 0 (main program)
N11000 PROC UP1 ; Program level 1
N11010 CALL "UP2"
N12000 PROC UP2 ; Program level 2
...
N19000 PROC ASUP ; Program level 3 (ASUB execution)
...
N19100 RET("N10900", ,$P_STACK) ; Subprogram return jump into the main program
; $P_STACK: actual program level
N10900 ; Target block in the main program
N10910 MCALL ; Deactivate the modal subprogram call
N10920 G0 G60 G40 M5 ; Initialize additional modal settings
Example 2: Character string (string>) to specify the target block search
Main program:
Program code Comment
PROC MAIN_PROGRAM
N1000 DEF INT iVar1=1, iVar2=4
N1010 ...
N1200 subProg1 ; Calls subprogram "subProg1"
N1210 M2 S1000 X10 F1000
N1220 ......
N1400 subProg2 ; Calls subprogram "subProg2"
N1410 M3 S500 Y20
N1420 ..
N1500 lab1: iVar1=R10*44
N1510 F500 X5
N1520 ...
N1550 subprog1: G1 X30 ; "subProg1" is defined here as jump marker.
N1560 ...
N1600 subProg3 ; Calls subprogram "subProg3"
N1610 ...
N1900 M30
Subprogram subProg1:
Program code Comment
PROC subProg1
Work preparation
3.2 Subprogram technique
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 515
