Directory Content
_N_CMA_DIR Manufacturer cycles
_N_CUS_DIR User cycles
_N_WKS_DIR Workpieces
_N_SPF_DIR Global subprograms
_N_MPF_DIR Main programs
_N_COM_DIR Comments
File types
The following file types can be stored in the main memory:
File type Description
<name>_MPF Main program
<name>_SPF Subprogram
<name>_TEA Machine data
<name>_SEA Setting data
<name>_TOA Tool offsets
<name>_UFR Work offsets/frame
<name>_INI Initialization files
<name>_GUD Global user data
<name>_RPA R parameters
<name>_COM Comment
<name>_DEF Definitions for global user data and macros
Workpiece main directory (_N_WKS_DIR)
The workpiece main directory exists in the standard setup of the program memory under the
name _N_WKS_DIR. The workpiece main directory contains all the workpiece directories for
the workpieces that you have programmed.
Workpiece directories (..._WPD)
A workpiece directory contains all files required for machining a workpiece. These can be main
programs, subprograms, any initialization programs and comment files.
The first time a part program is started, initialization programs are executed once, depending
on the selected program (in accordance with machine data MD11280 $MN_WPD_INI_MODE).
Example:
The workpiece directory _N_SHAFT_WPD, created for SHAFT workpiece contains the
following files:
File Description
_N_SHAFT_MPF Main program
_N_PART2_MPF Main program
Work preparation
3.4 File and Program Management
NC programming
552 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
