Program code Comment
N80 X0 Y0 Z0 A0 B0 C0 G17 T1 D1 F12000 ; Selection of the tool.
N90 TRAORI(1) ; Select orientation transformation.
N100 B4=-1 C4=1 ; Definition of the plane.
N110 G41 ORID CUT3DF G64 X10 Y0 Z0 ; Activate tool offset.
N120 X30
N130 Y20 A4=1 C4=1 ; Outside corner, new plane definition.
N140 B3=1 C3=5 ; Change in orientation with ORID.
N150 B3=1 C3=1 ; Change in orientation with ORID.
N160 X-10 A5=1 C5=2 ORIC
N170 A3=-2 C3=1 ; Change in orientation with ORIC.
N180 A3=-1 C3=1 ; Change in orientation with ORIC.
N190 Y-10 A4=-1 C4=3 ; New plane definition.
N200 X-20 Y-20 Z10 ; Inside corner with previous block.
N210 X-30 Y10 A4=1 C4=1 ; Inside corner, new plane definition.
N220 A3=1 B3=0.5 C3=1.7 ; Change in orientation with ORIC.
N230 X-20 Y30 A4=1 B4=-2 C4=3 ORID
N240 A3 = 0.5 B3=-0.5 C3=1 ; Change in orientation.
N250 X0 Y30 C4=1 ; Path movement, new plane,
; orientation with relative programming.
N260 BSPLINE X20 Z15 ; Spline begin, relative programming of the orien-
tation
N270 X30 Y25 Z18 ; remains active during spline.
N280 X40 Y20 Z13
N290 X45 Y0 PW=2 Z8
N300 Y-20
N310 G2 ORIMKS A30 B45 I-20 X25 Y-40 Z0 ; Helix, orientation with axis programming.
N320 G1 X0 A3=-0.123 B3=0.456 C3=2.789 B4=-1 C4=5
B5=-1 C5=2
; Path movement, orientation, non-constant plane.
N330 X-20 G40 ; Deactivation of the tool radius compensation.
N340 M30
Example 2: NC program (section) generated from a CAD system with CUT3DFD
Program code Comment
N01 G710
N03 T="12"
N06 S5305 M03
N07 G642
; Approaching the starting position in the MCS taking the tool length into account.
G00 G90 X-250.62787 Y-38.37944 A=DC(253.12719)
B-12.49543
G00 G90 Z251.80052
; End of positioning in the MCS.
;
Work preparation
3.13 Tool offsets
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 761
