Keyword Coupling characteristics / mean‐
ing
Syntax
CPMSTART Coupling behavior at part pro‐
gram start
CPMSTART[FAx]="<start behavior>"
"<start
behavior>":
"NONE" The current state of the cou‐
pling is retained.
"ON" Coupling switched-on. All
defined leading axis rela‐
tionships are activated.
This is also performed
when all or parts of these
leading axis relationships
are active, i.e. resynchroni‐
zation is performed even
with a completely activated
coupling.
"OF" The coupling is switched
off. When the relevant cou‐
pling module was created
without an explicit definition
(CPDEF), the coupling
module is deleted. Other‐
wise it is retained, i.e. it can
still be used.
"DEL" The coupling is deactivated
and then deleted.
CPMPRT Coupling response at part pro‐
gram start under block search
run via program test
CPMPRT[FAx]="<start behavior>"
"<start
behavior>":
see CPMSTART
CPLINTR Offset value of the input value of
a leading axis
CPLINTR[FAx,LAx]=<value>
CPLINSC Scaling factor of the input value
of a leading axis
CPLINSC[FAx,LAx]=<value>
CPLOUTTR Offset value for the output value
of a coupling
CPLOUTTR[FAx,LAx]=<value>
CPLOUTSC Scaling factor for the output val‐
ue of a coupling
CPLOUTSC[FAx,LAx]=<value>
CPSYNCOP Threshold value of position syn‐
chronism "Coarse"
CPSYNCOP[FAx]=<value>
CPSYNFIP Threshold value of position syn‐
chronism "Fine"
CPSYNFIP[FAx]=<value>
CPSYNCOP2 Second threshold value for the
"Coarse" position synchronism
CPSYNCOP2[FAx]=<value>
CPSYNFIP2 Second threshold value for the
"Fine" position synchronism
CPSYNFIP2[FAx]=<value>
CPSYNCOV Threshold value of velocity syn‐
chronism "Coarse"
CPSYNCOV[FAx]=<value>
CPSYNFIV Threshold value of velocity syn‐
chronism "Fine"
CPSYNFIV[FAx]=<value>
Work preparation
3.16 Axis couplings
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 939
