Error messages and error handling
12.6.1
If error conditions are detected in the cycles, an alarm is generated and the execution of the cycle is aborted.
Furthermore, the cycles display their messages in the message line of the control system. These messages will not interrupt
the program execution.
The errors with their reactions and the messages in the message line of the control system are described in conjunction with
the individual cycles.
Error handling in the cycles
Alarms with numbers between 61000 and 62999 generated in the cycles. This range of numbers, in turn, is divided again
with regard to alarm responses and cancel criteria.
The error text that is displayed together with the alarm number gives you more detailed information on the error cause.
Block preparation in the NC is aborted
62000 ... 62999 Clear key The block preparation is interrupted;
the cycle can be continued the follow-
ing key on the MCP after the alarm has
been cleared:
The error numbers are classified as follows:
6 _ X _ _
● X=0 General cycle alarms
● X=1 Alarms generated by the drilling/drilling pattern/milling cycles
● X=6 Alarms generated by the turning cycles
The cycles display their messages in the message line of the control system. These messages will not interrupt the program
execution.
Messages provide information with regard to a certain behavior of the cycles and with regard to the progress of machining
and are usually kept beyond a machining step or until the end of the cycle. An example of messages is as follows:
"Depth: according to the value for the relative depth" from all drilling cycles.
