3 Mounting and Commissioning
242
7UM61 Manual
C53000-G1176-C127-3
For devices up to release 7UM61.../BB check the jumpers for the set nominal voltage
of the integrated power supply according to Table 3-1, the quiescent state of the life
contact according to Table 3-2 and the selected pickup voltages of the binary inputs
BI1 through BI7 according to Table 3-3.
Table 3-1 Jumper settings for nominal voltage of the integrated power supply on the pro-
cessor printed circuit board B–CPU for 7UM61.../BB
Table 3-2 Jumper setting for the quiescent state of the life contact on the B–CPU proces-
sor PCB for 7UM61.../BB
Table 3-3 Jumper settings for the control voltages of binary inputs BI1 through BI7 on the
B–CPU processor PCB for 7UM61.../BB
1)
Factory settings for devices with rated power supply voltages 24 VDC to 125 VDC
2)
Factory settings for devices with rated power supply voltages 110 VDC to 220 VDC and
115/230 VAC
Jumper Rated voltage
60/110/125 VDC 110/125/220/250 V DC
115 V AC
24/48 VDC
X51 1–2 2–3
Jumpers
X51 to X53
Not used
X52 1–2 and 3–4 2–3
X53 1–2 2–3
interchangeable cannot be changed
Jumper Open in the quiescent
state
Closed in the quiescent
state
Presetting
X40 1–2 2–3 2–3
Binary Inputs Jumper 19 V Threshold
1)
88 V Threshold
2)
BI1 X21 L H
BI2 X22 L H
BI3 X23 L H
BI4 X24 L H
BI5 X25 L H
BI6 X26 L H
BI7 X27 L H
