A Appendix
392
7UM61 Manual
C53000-G1176-C127-3
- Reset Minimum and Maximum
counter (ResMinMax)
Min/Max meter IE_W ON *
- Reset meter (Meter res) Energy IE_W ON * BI
- Error Systeminterface (SysIn-
tErr.)
Protocol IE ON
OFF
*LEDBO
1 No Function configured (Not con-
figured)
Device EM
2 Function Not Available (Non Exis-
tent)
Device EM
3 >Synchronize Internal Real Time
Clock (>Time Synch)
Device EM_
W
* * * LED BI BO 135 48 1 No
4 >Trigger Waveform Capture
(>Trig.Wave.Cap.)
Osc. Fault Rec. EM * * m LED BI BO 135 49 1 Yes
5 >Reset LED (>Reset LED) Device EM * * * LED BI BO 135 50 1 Yes
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group EM * * * LED BI BO 135 51 1 Yes
8 >Setting Group Select Bit 1 (>Set
Group Bit1)
Change Group EM
15 >Test mode (>Test mode) Device EM * * * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device EM * * * LED BI BO 135 54 1 Yes
51 Device is Operational and Pro-
tecting (Device OK)
Device AM ON
OFF
* * LED BO 135 81 1 Yes
52 At Least 1 Protection Funct. is
Active (ProtActive)
Device IE ON
OFF
**LEDBO70181Yes
55 Reset Device (Reset Device) Device AM ON * * LED BO
56 Initial Start of Device (Initial Start) Device AM ON * * LED BO 70 5 1 No
60 Reset LED (Reset LED) Device AM_
W
ON * * LED BO 70 19 1 No
67 Resume (Resume) Device AM ON * * LED BO
68 Clock Synchronization Error
(Clock SyncError)
Device AM ON
OFF
**LEDBO
69 Daylight Saving Time (DayLight-
SavTime)
Device AM ON
OFF
**LEDBO
70 Setting calculation is running
(Settings Calc.)
Device AM ON
OFF
**LEDBO70221Yes
71 Settings Check (Settings Check) Device AM * * * LED BO
72 Level-2 change (Level-2 change) Device AM ON
OFF
**LEDBO
73 Local setting change (Local
change)
Device AM * * *
110 Event lost (Event Lost) Device AM_
W
ON * * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Device AM ON * m LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device AM ON
OFF
* * LED BO 135 145 1 Yes
140 Error with a summary alarm
(Error Sum Alarm)
Device AM * * * LED BO
147 Error Power Supply (Error Pwr-
Supply)
Device AM ON
OFF
**LEDBO
160 Alarm Summary Event (Alarm
Sum Event)
Device AM * * * LED BO 70 46 1 Yes
161 Failure: General Current Supervi-
sion (Fail I Superv.)
Measurem.Superv AM ON
OFF
**LEDBO70321Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
