A.8 Information List
397
7UM61 Manual
C53000-G1176-C127-3
1967 O/C prot. stage I> is ACTIVE (I>
ACTIVE)
O/C Prot. I> AM ON
OFF
* * LED BO 60 217 1 Yes
1970 O/C prot. undervoltage seal-in
(U< seal in)
O/C Prot. I> AM * ON
OFF
* LED BO 60 220 2 Yes
3953 >BLOCK impedance protection
(>Imp. BLOCK)
Impedance EM * * * LED BI BO
3956 >Zone 1B extension for imped-
ance prot. (>Extens. Z1B)
Impedance EM ON
OFF
* * LED BI BO 28 222 1 Yes
3958 >Imp. prot. : BLOCK undervolt-
age seal-in (>Useal-in BLK)
Impedance EM ON
OFF
**LEDBIBO28301Yes
3961 Impedance protection is switched
OFF (Imp. OFF)
Impedance AM ON
OFF
* * LED BO 28 226 1 Yes
3962 Impedance protection is
BLOCKED (Imp. BLOCKED)
Impedance AM ON
OFF
ON
OFF
* LED BO 28 227 1 Yes
3963 Impedance protection is ACTIVE
(Imp. ACTIVE)
Impedance AM ON
OFF
* * LED BO 28 228 1 Yes
3966 Impedance protection picked up
(Imp. picked up)
Impedance AM * ON
OFF
* LED BO 28 229 2 Yes
3967 Imp.: Fault detection , phase L1
(Imp. Fault L1)
Impedance AM * ON
OFF
* LED BO 28 230 2 Yes
3968 Imp.: Fault detection , phase L2
(Imp. Fault L2)
Impedance AM * ON
OFF
* LED BO 28 231 2 Yes
3969 Imp.: Fault detection , phase L3
(Imp. Fault L3)
Impedance AM * ON
OFF
* LED BO 28 232 2 Yes
3970 Imp.: O/C with undervoltage seal
in (Imp. I> & U<)
Impedance AM * ON
OFF
* LED BO 28 233 2 Yes
3977 Imp.: Z1< TRIP (Imp.Z1< TRIP) Impedance AM * ON m LED BO 28 240 2 Yes
3978 Imp.: Z1B< TRIP (Imp.Z1B<
TRIP)
Impedance AM * ON m LED BO 28 241 2 Yes
3979 Imp.: Z2< TRIP (Imp. Z2< TRIP) Impedance AM * ON m LED BO 28 242 2 Yes
3980 Imp.: T3> TRIP (Imp.T3> TRIP) Impedance AM * ON m LED BO 28 243 2 Yes
4523 >Block external trip 1 (>BLOCK
Ext 1)
External Trips EM * * * LED BI BO
4526 >Trigger external trip 1 (>Ext trip
1)
External Trips EM ON
OFF
* * LED BI BO 51 126 1 Yes
4531 External trip 1 is switched OFF
(Ext 1 OFF)
External Trips AM ON
OFF
* * LED BO 51 131 1 Yes
4532 External trip 1 is BLOCKED (Ext
1 BLOCKED)
External Trips AM ON
OFF
ON
OFF
* LED BO 51 132 1 Yes
4533 External trip 1 is ACTIVE (Ext 1
ACTIVE)
External Trips AM ON
OFF
* * LED BO 51 133 1 Yes
4536 External trip 1: General picked up
(Ext 1 picked up)
External Trips AM * ON
OFF
* LED BO 51 136 2 Yes
4537 External trip 1: General TRIP (Ext
1 Gen.TRP)
External Trips AM * ON * LED BO 51 137 2 Yes
4543 >BLOCK external trip 2 (>BLOCK
Ext 2)
External Trips EM * * * LED BI BO
4546 >Trigger external trip 2 (>Ext trip
2)
External Trips EM ON
OFF
* * LED BI BO 51 146 1 Yes
4551 External trip 2 is switched OFF
(Ext 2 OFF)
External Trips AM ON
OFF
* * LED BO 51 151 1 Yes
4552 External trip 2 is BLOCKED (Ext
2 BLOCKED)
External Trips AM ON
OFF
ON
OFF
* LED BO 51 152 1 Yes
4553 External trip 2 is ACTIVE (Ext 2
ACTIVE)
External Trips AM ON
OFF
* * LED BO 51 153 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
