A Appendix
398
7UM61 Manual
C53000-G1176-C127-3
4556 External trip 2: General picked up
(Ext 2 picked up)
External Trips AM * ON
OFF
* LED BO 51 156 2 Yes
4557 External trip 2: General TRIP (Ext
2 Gen.TRP)
External Trips AM * ON * LED BO 51 157 2 Yes
4563 >BLOCK external trip 3 (>BLOCK
Ext 3)
External Trips EM * * * LED BI BO
4566 >Trigger external trip 3 (>Ext trip
3)
External Trips EM ON
OFF
* * LED BI BO 51 166 1 Yes
4571 External trip 3 is switched OFF
(Ext 3 OFF)
External Trips AM ON
OFF
* * LED BO 51 171 1 Yes
4572 External trip 3 is BLOCKED (Ext
3 BLOCKED)
External Trips AM ON
OFF
ON
OFF
* LED BO 51 172 1 Yes
4573 External trip 3 is ACTIVE (Ext 3
ACTIVE)
External Trips AM ON
OFF
* * LED BO 51 173 1 Yes
4576 External trip 3: General picked up
(Ext 3 picked up)
External Trips AM * ON
OFF
* LED BO 51 176 2 Yes
4577 External trip 3: General TRIP (Ext
3 Gen.TRP)
External Trips AM * ON * LED BO 51 177 2 Yes
4583 >BLOCK external trip 4 (>BLOCK
Ext 4)
External Trips EM * * * LED BI BO
4586 >Trigger external trip 4 (>Ext trip
4)
External Trips EM ON
OFF
* * LED BI BO 51 186 1 Yes
4591 External trip 4 is switched OFF
(Ext 4 OFF)
External Trips AM ON
OFF
* * LED BO 51 191 1 Yes
4592 External trip 4 is BLOCKED (Ext
4 BLOCKED)
External Trips AM ON
OFF
ON
OFF
* LED BO 51 192 1 Yes
4593 External trip 4 is ACTIVE (Ext 4
ACTIVE)
External Trips AM ON
OFF
* * LED BO 51 193 1 Yes
4596 External trip 4: General picked up
(Ext 4 picked up)
External Trips AM * ON
OFF
* LED BO 51 196 2 Yes
4597 External trip 4: General TRIP (Ext
4 Gen.TRP)
External Trips AM * ON * LED BO 51 197 2 Yes
4822 >BLOCK Restart inhibit motor
(>BLK Re. Inhib.)
Restart Motor EM * * * LED BI BO
4823 >Emergency start rotor (>Emer.
Start ΘR)
Restart Motor EM ON
OFF
* * LED BI BO 168 51 1 Yes
4824 Restart inhibit motor is switched
OFF (Re. Inhibit OFF)
Restart Motor AM ON
OFF
* * LED BO 168 52 1 Yes
4825 Restart inhibit motor is
BLOCKED (Re. Inhibit BLK)
Restart Motor AM ON
OFF
* * LED BO 168 53 1 Yes
4826 Restart inhibit motor is ACTIVE
(Re. Inhibit ACT)
Restart Motor AM ON
OFF
* * LED BO 168 54 1 Yes
4827 Restart inhibit motor TRIP (Re.
Inhib. TRIP)
Restart Motor AM ON * * LED BO 168 55 1 Yes
4828 >Reset thermal memory rotor
(>RM th.rep. ΘR)
Restart Motor EM ON
OFF
**LEDBIBO
4829 Reset thermal memory rotor (RM
th.rep. ΘR)
Restart Motor AM ON
OFF
* * LED BO 168 50 1 Yes
4830 Alarm restart inhibit motor (Re. In-
hib.ALARM)
Restart Motor AM ON
OFF
**LEDBO
5002 Suitable measured quantities
present (Operat. Cond.)
P.System Data 1 AM ON
OFF
**LEDBO7121Yes
5010 >BLOCK fuse failure monitor
(>FFM BLOCK)
Measurem.Superv EM ON
OFF
ON
OFF
* LED BI BO 71 7 1 Yes
5011 >FFM extern undervoltage
(>FFM U< extern)
Measurem.Superv EM ON
OFF
**LEDBIBO7181Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
