A.8 Information List
399
7UM61 Manual
C53000-G1176-C127-3
5012 Voltage UL1E at trip (UL1E:) P.System Data 2 AM * ON
OFF
71 38 4 No
5013 Voltage UL2E at trip (UL2E:) P.System Data 2 AM * ON
OFF
71 39 4 No
5014 Voltage UL3E at trip (UL3E:) P.System Data 2 AM * ON
OFF
71 40 4 No
5015 Active power at trip (P:) P.System Data 2 AM * ON
OFF
71 41 4 No
5016 Reactive power at trip (Q:) P.System Data 2 AM * ON
OFF
71 42 4 No
5017 Frequency at trip (f:) P.System Data 2 AM * ON
OFF
71 43 4 No
5083 >BLOCK reverse power protec-
tion (>Pr BLOCK)
Reverse Power EM * * * LED BI BO
5086 >Stop valve tripped (>SV tripped) Reverse Power EM ON
OFF
**LEDBIBO70771Yes
5091 Reverse power prot. is switched
OFF (Pr OFF)
Reverse Power AM ON
OFF
**LEDBO70811Yes
5092 Reverse power protection is
BLOCKED (Pr BLOCKED)
Reverse Power AM ON
OFF
ON
OFF
* LED BO 70 82 1 Yes
5093 Reverse power protection is
ACTIVE (Pr ACTIVE)
Reverse Power AM ON
OFF
**LEDBO70831Yes
5096 Reverse power: picked up (Pr
picked up)
Reverse Power AM * ON
OFF
* LED BO 70 84 2 Yes
5097 Reverse power: TRIP (Pr TRIP) Reverse Power AM * ON m LED BO 70 85 2 Yes
5098 Reverse power: TRIP with stop
valve (Pr+SV TRIP)
Reverse Power AM * ON m LED BO 70 86 2 Yes
5113 >BLOCK forward power supervi-
sion (>Pf BLOCK)
Forward Power EM * * * LED BI BO
5116 >BLOCK forw. power superv. Pf<
stage (>Pf< BLOCK)
Forward Power EM ON
OFF
* * LED BI BO 70 102 1 Yes
5117 >BLOCK forw. power superv. Pf>
stage (>Pf> BLOCK)
Forward Power EM ON
OFF
* * LED BI BO 70 103 1 Yes
5121 Forward power supervis. is
switched OFF (Pf OFF)
Forward Power AM ON
OFF
* * LED BO 70 106 1 Yes
5122 Forward power supervision is
BLOCKED (Pf BLOCKED)
Forward Power AM ON
OFF
ON
OFF
* LED BO 70 107 1 Yes
5123 Forward power supervision is
ACTIVE (Pf ACTIVE)
Forward Power AM ON
OFF
* * LED BO 70 108 1 Yes
5126 Forward power: Pf< stage picked
up (Pf< picked up)
Forward Power AM * ON
OFF
* LED BO 70 109 2 Yes
5127 Forward power: Pf> stage picked
up (Pf> picked up)
Forward Power AM * ON
OFF
* LED BO 70 110 2 Yes
5128 Forward power: Pf< stage TRIP
(Pf< TRIP)
Forward Power AM * ON m LED BO 70 111 2 Yes
5129 Forward power: Pf> stage TRIP
(Pf> TRIP)
Forward Power AM * ON m LED BO 70 112 2 Yes
5143 >BLOCK I2 (Unbalance Load)
(>BLOCK I2)
Unbalance Load EM * * * LED BI BO
5145 >Reverse Phase Rotation (>Re-
verse Rot.)
P.System Data 1 EM ON
OFF
**LEDBIBO71341Yes
5146 >Reset memory for thermal
replica I2 (>RM th.rep. I2)
Unbalance Load EM ON
OFF
**LEDBIBO
5147 Phase Rotation L1L2L3 (Rotation
L1L2L3)
P.System Data 1 AM ON
OFF
* * LED BO 70 128 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
