A Appendix
400
7UM61 Manual
C53000-G1176-C127-3
5148 Phase Rotation L1L3L2 (Rotation
L1L3L2)
P.System Data 1 AM ON
OFF
* * LED BO 70 129 1 Yes
5151 I2 switched OFF (I2 OFF) Unbalance Load AM ON
OFF
* * LED BO 70 131 1 Yes
5152 I2 is BLOCKED (I2 BLOCKED) Unbalance Load AM ON
OFF
ON
OFF
* LED BO 70 132 1 Yes
5153 I2 is ACTIVE (I2 ACTIVE) Unbalance Load AM ON
OFF
* * LED BO 70 133 1 Yes
5156 Unbalanced load: Current
warning stage (I2> Warn)
Unbalance Load AM ON
OFF
* * LED BO 70 134 1 Yes
5158 Reset memory of thermal replica
I2 (RM th.rep. I2)
Unbalance Load AM ON
OFF
* * LED BO 70 137 1 Yes
5159 I2>> picked up (I2>> picked up) Unbalance Load AM * ON
OFF
* LED BO 70 138 2 Yes
5160 Unbalanced load: TRIP of current
stage (I2>> TRIP)
Unbalance Load AM * ON m LED BO 70 139 2 Yes
5161 Unbalanced load: TRIP of
thermal stage (I2 Θ TRIP)
Unbalance Load AM * ON m LED BO 70 140 2 Yes
5165 I2> picked up (I2> picked up) Unbalance Load AM * ON
OFF
* LED BO 70 150 2 Yes
5173 >BLOCK stator earth fault protec-
tion (>S/E/F BLOCK)
Stator E Fault EM * * * LED BI BO
5176 >Switch off earth current de-
tec.(S/E/F) (>S/E/F Iee off)
Stator E Fault EM ON
OFF
* * LED BI BO 70 152 1 Yes
5181 Stator earth fault prot. is switch
OFF (S/E/F OFF)
Stator E Fault AM ON
OFF
* * LED BO 70 156 1 Yes
5182 Stator earth fault protection is
BLOCK. (S/E/F BLOCKED)
Stator E Fault AM ON
OFF
ON
OFF
* LED BO 70 157 1 Yes
5183 Stator earth fault protection is
ACTIVE (S/E/F ACTIVE)
Stator E Fault AM ON
OFF
* * LED BO 70 158 1 Yes
5186 Stator earth fault: U0 picked up
(U0> picked up)
Stator E Fault AM * ON
OFF
* LED BO 70 159 2 Yes
5187 Stator earth fault: U0 stage TRIP
(U0> TRIP)
Stator E Fault AM * ON m LED BO 70 160 2 Yes
5188 Stator earth fault: I0 picked up
(3I0> picked up)
Stator E Fault AM * ON
OFF
* LED BO 70 168 2 Yes
5189 Earth fault in phase L1 (Uearth
L1)
Stator E Fault AM * ON
OFF
* LED BO 70 169 2 Yes
5190 Earth fault in phase L2 (Uearth
L2)
Stator E Fault AM * ON
OFF
* LED BO 70 170 2 Yes
5191 Earth fault in phase L3 (Uearth
L3)
Stator E Fault AM * ON
OFF
* LED BO 70 171 2 Yes
5193 Stator earth fault protection TRIP
(S/E/F TRIP)
Stator E Fault AM * ON m LED BO 70 173 2 Yes
5194 Stator earth fault: direction
forward (SEF Dir Forward)
Stator E Fault AM ON
OFF
* * LED BO 70 174 1 Yes
5203 >BLOCK frequency protection
(>BLOCK Freq.)
Frequency Prot. EM * * * LED BI BO
5206 >BLOCK stage f1 (>BLOCK f1) Frequency Prot. EM ON
OFF
* * LED BI BO 70 177 1 Yes
5207 >BLOCK stage f2 (>BLOCK f2) Frequency Prot. EM ON
OFF
* * LED BI BO 70 178 1 Yes
5208 >BLOCK stage f3 (>BLOCK f3) Frequency Prot. EM ON
OFF
* * LED BI BO 70 179 1 Yes
5209 >BLOCK stage f4 (>BLOCK f4) Frequency Prot. EM ON
OFF
* * LED BI BO 70 180 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
