A Appendix
402
7UM61 Manual
C53000-G1176-C127-3
5361 Overexcitation prot. is swiched
OFF (U/f> OFF)
Overexcitation AM ON
OFF
**LEDBO71831Yes
5362 Overexcitation prot. is BLOCKED
(U/f> BLOCKED)
Overexcitation AM ON
OFF
ON
OFF
* LED BO 71 84 1 Yes
5363 Overexcitation prot. is ACTIVE
(U/f> ACTIVE)
Overexcitation AM ON
OFF
**LEDBO71851Yes
5367 Overexc. prot.: U/f warning stage
(U/f> warn)
Overexcitation AM ON
OFF
**LEDBO71861Yes
5369 Reset memory of thermal replica
U/f (RM th.rep. U/f)
Overexcitation AM ON
OFF
**LEDBO71881Yes
5370 Overexc. prot.: U/f> picked up
(U/f> picked up)
Overexcitation AM * ON
OFF
* LED BO 71 89 2 Yes
5371 Overexc. prot.: TRIP of U/f>>
stage (U/f>> TRIP)
Overexcitation AM * ON m LED BO 71 90 2 Yes
5372 Overexc. prot.: TRIP of th. stage
(U/f> th.TRIP)
Overexcitation AM * ON m LED BO 71 91 2 Yes
5373 Overexc. prot.: U/f>> picked up
(U/f>> pick.up)
Overexcitation AM * ON
OFF
* LED BO 71 92 2 Yes
5396 Failure R/E/F protection Iee<
(Fail. REF Iee<)
Sens. E Fault AM ON
OFF
* * LED BO 71 126 1 Yes
5503 >BLOCK Rate-of-frequency-
change prot. (>df/dt block)
df/dt Protect. EM * * * LED BI BO
5504 >BLOCK df1/dt stage (>df1/dt
block)
df/dt Protect. EM ON
OFF
**LEDBIBO7211Yes
5505 >BLOCK df2/dt stage (>df2/dt
block)
df/dt Protect. EM ON
OFF
**LEDBIBO7221Yes
5506 >BLOCK df3/dt stage (>df3/dt
block)
df/dt Protect. EM ON
OFF
**LEDBIBO7231Yes
5507 >BLOCK df4/dt stage (>df4/dt
block)
df/dt Protect. EM ON
OFF
**LEDBIBO7241Yes
5511 df/dt is switched OFF (df/dt OFF) df/dt Protect. AM ON
OFF
**LEDBO7251Yes
5512 df/dt is BLOCKED (df/dt
BLOCKED)
df/dt Protect. AM ON
OFF
ON
OFF
*LED BO 726 1Yes
5513 df/dt is ACTIVE (df/dt ACTIVE) df/dt Protect. AM ON
OFF
**LEDBO7271Yes
5514 df/dt is blocked by undervoltage
(df/dt U< block)
df/dt Protect. AM ON
OFF
ON
OFF
*LED BO 728 1Yes
5516 Stage df1/dt picked up (df1/dt
pickup)
df/dt Protect. AM * ON
OFF
*LED BO 729 2Yes
5517 Stage df2/dt picked up (df2/dt
pickup)
df/dt Protect. AM * ON
OFF
* LED BO 72 10 2 Yes
5518 Stage df3/dt picked up (df3/dt
pickup)
df/dt Protect. AM * ON
OFF
*LED BO 72112Yes
5519 Stage df4/dt picked up (df4/dt
pickup)
df/dt Protect. AM * ON
OFF
* LED BO 72 12 2 Yes
5520 Stage df1/dt TRIP (df1/dt TRIP) df/dt Protect. AM * ON * LED BO 72 13 2 Yes
5521 Stage df2/dt TRIP (df2/dt TRIP) df/dt Protect. AM * ON * LED BO 72 14 2 Yes
5522 Stage df3/dt TRIP (df3/dt TRIP) df/dt Protect. AM * ON * LED BO 72 15 2 Yes
5523 Stage df4/dt TRIP (df4/dt TRIP) df/dt Protect. AM * ON * LED BO 72 16 2 Yes
5533 >BLOCK inadvertent energ. prot.
(>BLOCK I.En.)
Inadvert. En. EM * * * LED BI BO
5541 Inadvert. Energ. prot. is swiched
OFF (I.En. OFF)
Inadvert. En. AM ON
OFF
**LEDBO72311Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
