2.8 Inverse-Time Overcurrent Protection (ANSI 51V)
55
7UM61 Manual
C53000-G1176-C127-3
Figure 2-12 Logic Diagram of the Voltage Controlled Inverse Overcurrent Time Protection
The changeover to the lower current pickup value on decreasing voltage (loop enable)
is performed on a phase by phase basis in accordance with Table 2-3.
