SIRIUS - SIRIUS 3RT Contactors/Contactor assemblies
Manual, 09/2017, A5E03656507120A/RS-AE/006
179
Hazardous voltage. Will cause death or serious injury.
Turn off and lock out all power supplying this device before working on this device.
Note the following information when mounting contactors:
● If foreign bodies (such as drillings) can reach the devices, the contactors must be covered
during mounting.
● If there is a risk of pollution, heavy dust deposits, or an aggressive atmosphere at the
mounting location, the contactors must be installed in an enclosure.
● Dust deposits must be vacuumed away.
The following mounting types are available for the contactors:
● Snapping onto a 35 mm DIN rail according to IEC 60715. (Sizes S00 ... S3 only)
● Screwing onto a mounting plate
Up to an ambient temperature of 60 °C, derating is not necessary for all contactors even in
the case of side-by-side mounting. In the case of contactors with extended operating range
(0.7 to 1.25 x U
s
) that operate via a series resistor, side-by-side mounting is permissible up
to an ambient temperature of +70 °C.
