Accessories
9.26 Assembly kit for reversing contactor assemblies (sizes S00 to S3)
SIRIUS - SIRIUS 3RT Contactors/Contactor assemblies
366 Manual, 09/2017, A5E03656507120A/RS-AE/006
Assembly kit for reversing contactor assemblies (sizes S00 to S3)
9.26.1
Users can mount the 3RA23 reversing contactor assembly using various assembly kits for
screw and spring-loaded connections.
/ 3RT202. / 3RT203. / 3RT204. power contactors required for installing the
reversing contactor assembly in sizes S00 to S3 have to be ordered separately.
Assembly kit for 3RA23 reversing contactor assembly
The following components are included in delivery with the assembly kit for 3RA23 reversing
contactor assembly:
● Sizes S00 / S0
– Mechanical interlock
– 2 connecting clips for 2 contactors
– Wiring modules, top and bottom
– Auxiliary wiring module top and bottom
● Sizes S2 / S3
– 2 connecting pins
– Wiring modules, top and bottom
– Auxiliary wiring modules top and bottom with screw connection only
– 3 cables with spring-loaded connection
e mechanical interlock for sizes S2 / S3 must be ordered separately as an accessory.
