Accessories
9.10 Coupling link for PLC
SIRIUS - SIRIUS 3RT Contactors/Contactor assemblies
334 Manual, 09/2017, A5E03656507120A/RS-AE/006
Mounting the 3RH2924-1GP11 coupling link
Prerequisite
The 3RT2926-4R..... coil terminal module must be mounted before you can attach the
coupling link.
Before mounting the coupling link, disconnect the voltage from L1 to L3.
Attach the coupling link to the coil terminal module using the two integrated mounting pins.
Screw the coupling link tight with a screwdriver.
