9.21.3
Operation
Table 9- 36 Operating the pneumatically delayed auxiliary switch
Step
Instructions
Figure
1
Set the required time range.
2 Press the plunger to start the pneumatically
delayed auxiliary switch.
3 Once the set time has elapsed, the plunger
will snap back out.
