Installing / mounting
4.4 "Level" installation
SITRANS P DS III with PROFIBUS PA
48 Operating Instructions, 06/2013, A5E00053276-07
Figure 4-3 An example of fastening on the mounting bracket in the case of differential pressure and vertical differential
pressure lines
4.4
"Level" installation
4.4.1
Instructions for level installation
Requirements
Note
Compare the desired operating data with the data on the nameplate.
Please also refer to the information on the remote seal if this is fitted.
