94 SDS1000CML+/SDS1000DL+ User Manual
<0.04div-4.00div>
Create
Mask
Create a test mask according to the above
clearance.
Location
Internal
External
Select position to store created mask.
Next Page Page 1/2
Enter the second page of “Mask Setting
menu”.
Picture2.13-14
Table 2-58 Mask Setting function menu 2:
Option
Setting
Instruction
Save Store created mask setting.
Load Recall stored mask setting.
Return Return to the main menu of mask setting.
Last Page
Page 2/2
Return to the first page of “Mask Setting menu”.
Picture 2.13-15
