Simrad AP35 Autopilot
72 22083083H
Installation Settings Menu
The Installation Settings Menu (ISM) is presented on the autopilot display
by pressing and holding the NAV/SETUP pushbutton for 5 seconds.
Note ! The INSTALLATION SETTINGS MENU is different from the USER SETUP
MENU . Refer to flow diagram on the next page for a pictorial view of
Installation Settings Menu .
There are several actions that you can do once you have accessed the ISM:
• Answer YES to the question by rotating the course dial clockwise
• Proceed to the next item in the menu by pressing the STBD pushbutton.
(Proceeding to the next item when presented with a question is the same
as answering NO to the question.)
• Proceed back to the previous item in the menu by pressing the PORT
button
• Change the selected item shown rotating the course dial
• Leave the ISM by selecting STBY, AUTO, WORK or NAV.
On new installations, and whenever a control unit, junction unit, or software
is replaced in an AP35 system, it is recommended that a MASTER RESET
be performed as described in the ISM prior to proceeding with the setup
procedure.
When using the ISM refer to diagram "Installation settings Menu Flow
Chart" on next page.
Language selection
The AP35 can present the display in eight different languages:
• English, Norsk, Francais, Espanol, Italiano, Nederlands, Svenska and
Deutsch.
To access the language selection in the ISM:
1. Turn on the equipment and wait approx. 5 seconds.
2. Press the NAV/setup button for about 5 seconds until the display is
changed to:
INSTALLATION
Language
English
3. Turn the course dial until the language you wish to use is displayed.
4. Leave the ISM by a press on the STBY button, or continue to next item in
the ISM by pressing STBD [>] button.
