Installation
22083083H 79
The Master Reset needs a double confirmation to prevent an unwanted reset.
To perform a Master Reset, rotate the course selector clockwise and observe
the display; then rotate the course selector counter clockwise.
Interface Settings
The AP35 system provides a totally flexible approach to the input of data
from heading sensors and other peripheral equipment. Identification of the
type of equipment connected to the AP35 system is performed in the
Interface Setup Menu.
If your system includes connection of external equipment to the NMEA0183
data ports in Junction Unit or NI300X, or if the CI300X is installed with
optional compass units or an optional analog wind vane unit, they must be
configured under this menu. This procedure allows you to assign an
abbreviated name to identify the type of equipment that is connected to each
of the available hardware ports in the AP35 system.
Abbreviated name Equipment / Usage NOTES
GPS1 Primary GPS Can be used as either NAV
GPS2 Backup GPS
source or POS source. Also for
VTG data for automatic
LC 1 Primary Loran
AUTO HI/LO speed selection
LC 2 Backup Loran
NAV1 Chart plotter
NAV2 Other Nav source
INSTR Source of data for automatic HI/LO
parameter selection
Uses log input (VHW) for speed
data
RFC For use when selecting between
Simrad fluxgate compasses
RFC35 fluxgate compass is
connected to junction unit. RC25
rate compass is connected to
Robnet
MAGN Magnetic compass with course
detector (CD100A)
CDI35 + CD100A is connected to
junction unit.
CD100A only must be connected
to CI300X.
FLUXG For use with non-Simrad fluxgate
compasses that output SIN/COS
Optional CI300X item.
GYRO For use with Simrad RGC50,
RGC10 and RGC11 gyro if using
1:1 synchro.
Optional CI300X item. True data
displayed for heading COG,
bearing to waypoint.
NMEA For use with NMEA compasses Gyro, THD, or other.
