Output INSTR NMEA output of compass heading HDG or HDT output increased
from 1 to 5 times/sec. on TX1 port
Output RADAR Clock/data heading output to radars Selectable between Simrad/Anritsu
and Furuno. (On both J300X and
NI300X)
Note ! If using J300X, TX2 outputs HDT or HDG at 10 Hz constantly.
The Interface Setup Menu presents these names so that they can be assigned
to a hardware input or output port. Each abbreviated name is then presented
in appropriate locations of the USER SETUP MENU to provide the user
with choices of data sources, or identified to the AP35 where to look for
various types of data.
When you assign a hardware port to an abbreviated name, you are simply
telling the AP35 system that when the user chooses an abbreviated name as a
data source it should look to the hardware port assigned to the abbreviated
name for the data.
Upon completion of the ISM it is recommended to record the configuration
in the Interface Setup Table on page 81.
• Enter the Interface Setup part of the ISM.
• Scroll through to the Interface setup ? prompt by pressing the STBD [>]
The following display will be presented:
INSTALLATION
Interface
Setup?
To access the Interface Setup items, turn the course selector clockwise.
The display will show:
INSTALLATION
Input:
GPS1: -
The display is now showing the first name on the list. Assign a hardware
port to the name by turning the course selector until the hardware port is
displayed.
Proceed to the names on the list that shall be assigned by pressing STBD [>]
button. Select appropriate NMEA ports by turning the course selector, or exit
from menu by stepping through the list of names by pushing STBD [>]
button.
Note ! At the completion of the Interface Setup, the names of items that you have
assigned hardware ports to will be available as sources of data for NAV
(navigation), POS (position) and COMPASS in the USER SETUP MENU. It
is recommended that you access the User Setup Menu directly after
completing the Interface Setup to select the desired data. Refer to page 27
for details on changing the items in the User Setup Menu.
