Simrad AP35 User Manual

Installation
22083083H 81
Interface setup - input signal
Setup item
(abbrev.
name)
Equipment
connected
Connected to terminal
(use one available from list)
Assign hardware
port to setup item
(* = default setting)
GPS1 Not connected –
J3XX, Main PCB NMEA I/P
RX1+,RX1–
J300X-1 *
(on J3000X)
J300X, Power PCB NMEA I/P
RX2+,RX2–
J300X-2 *
(on J300X and J300X-
40)
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
GPS2 Not connected – *
J300X, Main PCB NMEA I/P
RX1+,RX1–
J300X-1
J300X, Power PCB NMEA I/P
RX2+,RX2–
J300X-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
LC1 Not connected – *
J3XX, Main PCB NMEA I/P
RX1+,RX1–
J300X-1
J300X, Power PCB NMEA I/P
RX2+,RX2–
J300X-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
LC2 Not connected – *
J300X, Main PCB NMEA I/P
RX1+,RX1–
J300X-1
J300X, Power PCB NMEA I/P
RX2+,RX2–
J300X-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
NAV1 Not connected – *
J3XX, Main PCB NMEA I/P
RX1+,RX1–
J300X-1
J300X, Power PCB NMEA I/P
RX2+,RX2–
J300X-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
J3XX = All junction unit models
