Simrad NSS evo3S Installation Manual

NMEA 0183 supported sentences
TX / RX - GPS
Name Description RX TX
DTM Datum reference x
GGA Global positioning system (GPS) fix data x x
GLC Geographic position - Loran-C
GLL Geograpic position - Latitude/longitude x x
GSA GNSS DOP and active satellites x x
GNS GNSS fix data x
GSV GNSS satellites in view x x
VTG Course over ground and ground speed x x
ZDA Time and date x x
TX / RX - Navigation
Name Description RX TX
AAM Waypoint arrival alarm x
APB Heading/track controller (autopilot) sentence B x
BOD Bearing origin to destination x
BWC Bearing and distance to waypoint - Great circle x
BWR Bearing and distance to waypoint - Rhumb line x
RMB Recommended minimum navigation information x
XTE Cross-track error - measured x
RTE Routes x
WPL Waypoint location x
TX / RX - Sonar
Name Description RX TX
DBT Depth below transducer x x
DPT Depth x x
MTW Water temperature x x
VLW Dual ground/water distance x x
VHW Water speed and heading x x
TX / RX - Compass
Name Description RX TX
HDG Heading, deviation and variation x x
HDT Heading true x
THS True heading and status x x
ROT Rate of turn x
Appendix | NSS evo3S Installation Manual
49

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
