Simrad NSS evo3S Installation Manual

TX / RX - Wind
Name Description RX TX
MWD Wind direction and speed x x
MWV Wind speed and angle x x
TX / RX - AIS / DSC
Name Description RX TX
DSC Digital selective calling information x
DSE Expanded digital selective calling x
VDM AIS VHF data-link message x
VDO AIS VHF data-link own-vessel report x
Ú
Note: AIS sentences are not bridged to or from NMEA 2000.
TX / RX - MARPA
Name Description RX TX
TLL Target latitude and longitude x
TTM Tracked target message x
Ú
Note: These are only output sentences.
Radar
Name Description RX TX
RSD Radar system data *x
OSD Own ship data *x
Ú
Note: *x - only transmitting when the radar panel is displayed.
MISC
Name Description RX TX
MOB Man over board notification x
VBW Dual ground/water speed x
XDR Transducer measurement x x
50
Appendix | NSS evo3S Installation Manual

Simrad NSS evo3S Specifications

General

Connectivity	Wi-Fi, Bluetooth, NMEA 2000, Ethernet
Internal Memory	16 GB
External Memory	microSD card slot
Waterproof Rating	IPX6
Resolution	1280 x 720
Sonar	DownScan, SideScan
GPS	Built-in GPS/GLONASS
Processor	iMX8
Operating Voltage	10-32 V DC
Ethernet Ports	2
Radar Compatibility	Halo
Operating Temperature	-15°C to +55°C
Storage Temperature	-20°C to +60°C
Dimensions	Varies by model
Weight	Varies by model
Display Size	9, 12, or 16 inches
