Simrad SU90 User Manual

106
381291/C
Deningtheuser-selectedfeaturesonthe
OperatingPanel
Topics
SelectingwhichOperatingPaneltouse,page106
AssigningcustomusersettingstotheOperatingPanel,page107
AssigningfunctionstotherotaryswitchesontheOperatingPanel,page109
AssigningfunctionstoF1,F2andF3ontheOperatingPanel,page110
SelectingwhichOperatingPaneltouse
TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationofthe
SU90.
Context
ThecontrolsprovidedbytheOperatingPanelare
arrangedinlogicalfunctionalgroups.Thisoffers
youclearandeasyoperationwithfastaccesstokey
functionality.ThemajorityoftheSU90functionscan
beaccessedusingthetrackballontheOperatingPanel
andthemenusystemshownintheSU90presentation.
Tip
YoucanalsouseastandardcomputermousetocontroltheSU90.Themousecanbe
connectedtoeithertheOperatingPanelordirectlytotheProcessorUnit.
TheSU90supportstwodifferentoperatingpanels.Thesearereferredtoas"Mk1"and
"Mk2".
•Mk1:TheOperatingPanelisconnectedtotheProcessorUnitwiththreecables.The
dualinterfacecableprovidespowerandserialcommunication.TheUSBinterface
cableisusedtoreadthetrackballmovements.Asmallcommercialpowersupplyis
usedtoprovidepowertotheSU90OperatingPanel.
•Mk2:AdedicatedEthernetcableisusedtoconnecttheOperatingPaneltothe
ProcessorUnit.TheOperatingPanelisprovidedwithabuilt-inpowersupply.
Toselectwhichoperatingpaneltouse,opentheOperatingPanelpageintheInstallation
dialogbox.TheInstallationdialogboxislocatedontheSetupmenu.
SimradSU90OperatorManual
