2Turntherelevantrotaryswitchtomaketheadjustment.

Tip

TheOperatingPanelisttedwiththreerotaryswitches.Theswitchesareidentied

withnumbers.Eachswitchcanbeassignedafunctionrelatedtorange,gainor

bearing.InvestigatethefunctionalityprovidedontheOperatingPanelpage.This

pageislocatedintheInstallationdialogbox.

Optionally:

3ObservetheMainmenu.

ItsdefaultlocationisontherightsideoftheSU90presentation.

4SelectRange.

5Makethenecessaryadjustment.

Select[+]or[-]tochoosetherequestedsetting.

or:

Placethecursoronthebutton.Pressandholdtheleft

mousebutton.Movethe

cursorhorizontallyoverthebutton.Releasethemousebuttonwhenrequested

valueisshown.

or:

Selectthemiddleofthebuttontoopenit.Ifyouhaveakeyboardconnectedtothe

SU90,youcantypetherequestedvalue.

or:

Selectthemiddleofthebuttontoopenit.Selectavaluefromtheoptionsprovided.

6OpenthebuttonandselectApplytoallifyouwishtousethechosensettinginall

theviewsinthecurrentpresentationmode.

Relatedtopics

Startingnormaloperation,page20

Adjustingtheechosensitivity

Someechoesareweakwhileothersarestronger.Tocompensateforthisitisoften

necessarytoadjustthesensitivityoftheSU90.Thisadjustmentiscommonlyreferred

toasgain.

Context

Youcancomparethisgainsettingwiththevolumecontrolonyourcarradio.When

thegainisincreased,theechoeswillappearstronger.Weakechoeswillbeeasierto

Gettingstarted
