381291/C

OperatingPaneldescription

TheSU90OperatingPanelisthemostimportantdeviceforfastandefcientuser

interface.TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperation

oftheSU90.

ThecontrolsprovidedbytheOperatingPanelarearrangedinlogicalfunctionalgroups.

Thisoffersyouclearandeasyoperationwithfastaccesstokeyfunctionality.The

majorityoftheSU90functionscanbeaccessedusingthetrackballontheOperating

PanelandthemenusystemshownintheSU90presentation.TheOperatingPanelallows

youtoassigncertainfunctionstodedicatedbuttonsandswitches.

Tip

AUSBsocketisprovidedinthetopleftcorneroftheOperatingPanel.Usethissocketto

connectacomputerkeyboard,amouseoraUSBashdrive.

APower:PressthisbuttontoturntheSU90onandoff.

•BeforeyouturnontheSU90,makesurethatyouhavesufcientwaterdepthto

lowerthetransducer!

•YoumustneverturnontheSU90whentheshipisindrydock.Thetransducer

maybedamagedifittransmitsinopenair.

•YoumustneverturnofftheSU90bymeansoftheon/offswitchontheProcessor

Unit.YoumustALW AYSusetheOperatingPanel.

BSonarSelect:SincetheOperatingPanelusesEthernettocommunicatewiththe

ProcessorUnit,youcanuseonesinglepaneltocontrolmorethanonesonarsystem.

Tochangewhichsonartocontrol,pressSonarSelectontheOperatingPanel.If

youuseyourOperatingPaneltocontrolmorethantwosonars,pressSonarSelect

repeatedlytoselect.

CUserSettings:PressoneoftheUserSettingsbuttonstoapplyapredeneduser

setting.TochoosewhichfunctiontoapplyopentheOperatingPanelpage.Under

Gettingstarted
