381291/C
119
Settinguptheinterfacestoperipheral
devices
Topics
Installingnavigationsensorsandothersensors,page119
DeningtheserialandEthernet(LAN)portparameters,page120
Settinguptheinputfromanavigationsystem(GPS),page122
Settinguptheinterfaceforspeedloginput,page124
Settinguptheinterfaceforcoursegyroinput,page126
Conguringthesensorinterface,page129
Settinguptheinputfromamotionreferenceunit(MRU),page130
SettinguptheSU90inasynchronizedsystem,page132
Installingnavigationsensorsandothersensors
FortheSU90touseandoffercorrectnavigationalinformation,oneormoreexternal
sensorsmustbeconnected.Typicalsensorsarethosethatprovidespeed,heading
andgeographicalposition.Tosetupthecommunicationparametersontheserialand
LANports,usetheI/OSetuppage.Toselectwhichsensorstoinstall,usetheSensor
Installationpage.TheSensorCongurationpageallowsyoutodeneadatagrampriority,
sothattheinformationfromthe"mostreliable"sensorisusedbytheSU90.Youcanalso
denemanualvaluesincaseasensorisunserviceable,ornotinstalled.
Prerequisites
ThenewsensorisphysicallyconnectedtotheSU90usingaserialornetworkcable.
Context
TheSensorInstallationpageallowsyourSU90tocommunicatewithexternalsensors
andsystems.However,inordertocommunicatewitheachsensor,youmustrstsetup
therelevantcommunicationparameters.Oncethecommunicationhasbeenestablished
andthesensorisconnected,youmustdenethedatagrampriorityandnalizethe
conguration.
Note
JustmakingchangesandselectingOKatthebottomofthepagewillnotinstallanything.
Selectwhattoinstall,denetherelevantparameters,andthenselectAdd.
Operatingprocedures
