381291/C

109

AssigningfunctionstotherotaryswitchesontheOperating

Panel

TheOperatingPanelisttedwiththreerotaryswitches.Theswitchesareidentiedwith

numbers.Eachswitchcanbeassignedafunctionrelatedtorange,gainorbearing.

Context

TheOperatingPanelpageisusedtoselectwhich

physicalhardwarepanelyouuseonyourSU90,and

toassignfunctionalitytotheprogrammablebuttons.

ThispageislocatedintheInstallationdialogbox.The

InstallationdialogboxislocatedontheSetupmenu.

Note

TheSU90supportstwodifferentoperatingpanels.Thesearereferredtoas"Mk1"and

"Mk2".Inthispublicationalldescriptionsandreferencesarerelatedto"Mk2".

Procedure

1OpentheSetupmenu.

2OntheSetupmenu,selectInstallation.

ObservethattheInstallationmenuopens.

Thisdialogboxcontainsanumberofpages

selectedfromthemenuontheleftside.

3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.

4SelectOperatingPanelMk2.

5UnderRotarySwitchOptions,assignonefunctiontoeachrotaryswitchonthe

OperatingPanel.

Thefollowingfunctionscanbecontrolled:

•HorizontalRange:Rangesettinginthehorizontalviews.

•VerticalRange:Rangesettingintheverticalviews.

•InspectionRange:Rangesettingintheinspectionviews.Thisfunctionis

currentlynotsupportedbytheSU90.

•ActivePingRange:Rangesettingintheactiveview.

•ActivePingGain:Gainsettingintheactiveview.

•ActivePingBearing:Bearingsettingintheactiveview.

6Atthebottomofthepage,selectApplytosaveyoursettings.

7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.

Relatedtopics

Deningtheuser-selectedfeaturesontheOperatingPanel,page106

Operatingprocedures
